Specifications
| Warranty | Up to 15-year limited warranty |
| Rangedown | Up to 150:1 |
| Communication Protocol | 4-20 mA HART, WirelessHART®, FOUNDATION™ Fieldbus |
| Measurement Range | Up to 150 psi (10.34 bar) Differential with maximum working pressure up to 15,000 psi (1034 bar) |
| Process Wetted Material | Alloy C-276 |
| Diagnostics | Basic Diagnostics, Loop Integrity, Process Intelligence, Plugged Impulse Line |
| Certifications/Approvals | SIL 2/3 certified to IEC 61508 by an independent 3rd party, NACE, hazardous location, see full specs for complete list of certifications |
Features
- SuperModule design withstands static lines pressures of up to 15000 psi (1,034 bar)
- Multivariable transmitter capable of differential pressure and temperature measurements
- Innovative, compact, coplanar platform reduces up to 60% of the weight versus today’s high pressure transmitters
- All-welded, hermetic design of the SuperModule platform resists overpressure and line pressure effects to ensure 0.055% accuracy
- Robust design, backed by 10-year stability, withstands the harshest production environments
- Integrates seamlessly with 4-20 mA HART®, WirelessHART®, FOUNDATION™ fieldbus protocols for application flexibility
- Advanced diagnostics offer comprehensive diagnostic coverage from the process to the transmitter to the host
- SIL 2/3 certified to IEC 61508 by an 3rd party and prior-use certificate of FMEDA data for safety installations
