| Warranty |
Up to 15-year limited warranty |
| Range down |
Up to 200:1 (14:1 flow turndown) |
| Measurement Range |
Up to 1000 inH2O (2.48 bar) differential, Up to 3626 psia (250.00 bar) absolute, Up to 3626 psig (250.00 bar) gage |
| Line Size |
0.5 to 12 in. (15 to 300 mm) |
| Output |
Differential pressure, static pressure, process temperature, scaled variable, mass flow, volumetric flow, energy flow |
| Communication Protocol |
4-20 mA HART®, WirelessHART®, FOUNDATION™ Fieldbus |
| Process Wetted Material |
316 SST |
| Diagnostics |
Basic Diagnostics, Loop Integrity, Process Intelligence, Plugged Impulse Line |
| Certifications/Approvals |
SIL 2/3 certified to IEC 61508 by an independent 3rd party, NACE, hazardous location, see full specs for complete list of certifications |
| Update Rate |
1 sec. to 60 min., user selectable |
| Power Module Life |
Up to 10-year life, field replaceable (order separately) |
| Wireless Range |
Long range (225 m), extended range (800 m), remote (225 m) and high-gain remote (1 km) |
